Material:
Contact: Brass
Contact Plating: 0.000150" Tin over 0.000100" Nickel Underplating
Insulator: Nylon 66; rated UL94V-O
Applicable Wire: 18 ~ 22 awg

Electrical:

Voltage Rating: 250V AC/DC
Current Rating: 7 Amp Max.
Contact Resistance: 20 Milliohms. Max.
Insulation Resistance: 500 Megohms Min. DC 500V
Dielectric Strength: 1500V AC
Operation Temperature: -25^oC to +85^oC
